2+2 seater black and black&grey seater

Product Category:

Golf carts

On road

4 seats

Powerful motor and engine High quality gel battery Guaranteed quality and service Factory direct prices Two years warranty

  • Electric
  • Steam power
    • 商品名称: 2+2 seater black and black&grey seater
    • 商品编号: JH-166

    Powerful motor and engine High quality gel battery Guaranteed quality and service Factory direct prices Two years warranty

    Standard Specifications
    Item Number: JHGF-E2-2S
    Brand: JINGHANG
    Type: E or Y type
    Power system
    Motor: 4kw AC
    Battery: Chillwee brand 48v,8v/150Ah, 6 Cells maintenance free(gel)battery
    Controller: 48v 400ah  charger: 48v 25ah intelligent
    Transimission: Motor direct drive Charge time: around 8 hours
    Body System
    Frame: More thicker strong steel made by ourself  with plastic powder spraying (Anti rust)
    Steering: Rack and opinion
    Color: White color or other colors
    Windscreen: Foldable organic glass Body: Strong Injected PP
    Wheel track (front/rear): 840mm/985mm  Ground clearance: 127mm
    Wheel base : 1640mm    Min.Turning Radius:  2900mm
    Product size:  2750*1200*1710mm  Packing size: 2300x1230x1000mm
    Curb weight:  460kgs Suspension: Front independent &Rear heavy duty leaf spring
    Brakes: rear drum brake&pedal park brake Tires: 18/8.5-8 Tubeless with iron rim and wheel hub cover
    Performance
    Max range each full charge(loaded on flat road): More than 90kms
    Braking distance: ≤4m Max. slope of climb:  40%(full loaded)
    Max. speed: 25-40KM/H(adjustable) Max load: More than 600kgs
    Container Loading
    Packing: Packing with iron frame(with wheels assembled and roof seat disassembled)
    Container Loading:  20GP(10pcs) ,40GP(20pcs),40HQ(30pcs)
    Combination Switch: Combination switch of Turnning lights,head lights and horn.
    electronic systems: Turnning signals,LED head lights,rear lights,brake nights,night rear lights,horn,battery level indicator,forward&reverse switch,electric locker,Reverse beeper.
    Free parts: 2% free parts for the container order
    Options:
    Rain cover, sun shade, galvanized frame, usb music player,lithium battery, 48v 210ah maintenance free battery,10inch or 12 inch alloy rim, off road tyre,, customized colors, sand bottle,ball washer, led lights,rear flip seat.golf bag holder,etc.............
    • Golf carts,Sightseeing car
  • Standard Specifications
    Item Number: JHGF-EG2-2S
    Brand: JINGHANG
    Type: E or Y type
    Power system
    Engine:: Durable  GY6 300CC, four stroke, single cylinder, water cooled
    Max power: 19KW(25.84HP) Max Torque: 26N.m
    Steering: Rack and opinion Start battery: 12v/12ah dry battery
    Transimission: Shaft drive Gear Shift: CVT(F-N-R)
    Body System
    Frame: More thicker strong steel made by ourself  with plastic powder spraying (Anti rust)
    Color: White color OR other colors
    Windscreen: Unfoldable Or Foldable Body: Strong Injected PP
    Wheel track (front/rear): 840mm/985mm  Ground clearance: 127mm
    Wheel base : 1640mm    Min.Turning Radius:  2900mm
    Product size:  2750*1200*1710mm  Packing size: 2300x1230x1000mm
    Curb weight:  370kgs Suspension: Front independent &Rear heavy duty leaf spring
    Brakes: Rear hydraulic brake Tires: 205/50-10 Tubeless with iron rim and wheel hub cover
    Performance
    Max load capacity: More than 600kgs Braking distance: ≤4m
    Fuel Tank: 12L Max. slope of climb:  45%
    Max. speed: 50KM/H Range per full tank: More than 300kms
    Container Loading
    Packing: Packing with iron frame(with wheels assembled and roof seat disassembled)
    Container Loading:  20GP(10pcs) ,40GP(20pcs),40HQ(30pcs)
    Combination Switch: Combination switch of Turnning lights,head lights and horn.
    electronic systems: Turnning signals,rear lights,brake nights,night rear lights,horn,,electric locker,led head lights,reverse beeper,,etc
    Options:
    Rain cover, sun shade, usb music player, candy stand, galvanized frame, customized colors, sand bottle,ball washer, led lights,rear flip seat,rear u shape handle bar,rear golf bag holder,etc.............
